SCHNEIDER 3 pole CONTACTOR LC1D09 M7 in 220V AC COIL Operating
Cat No./ Model No : LC1D09
Brand Name : SCHNEIDER
SCHNEIDER 3 pole CONTACTOR LC1D09 M7 in 220V AC COIL Operating
9 AMPS 3 POLE SCHNEIDER make CONTACTOR LC1D09 model
OTHER BRANDS of same product :- SIEMENS, L&T, TC(C&S)
Brand Name :- SCHNEIDER
Product Name :- CONTACTOR
Cat No./ Model No :- LC1D09
Type :- LC1D09M7 in 220V AC
SCHNEIDER
CONTACTOR
LC1D09
CONTACTOR
LC1D09
SCHNEIDER
LC1D09
SCHNEIDER 9 AMP, 220V AC, 3 POLE Power CONTACTOR
TeSys D contactor, 3 poles (3NO), for motor control applications up to 9A/690V AC-3/3e (4kW@400V). It provides a 220V 50/60Hz AC coil, 1NO+1NC built-in auxiliary contacts (NC mirror certified), connection by screw clamp terminals. For operating rates until 3600 cycles/hour and environments until 60°C, it procures high reliability and durability to demanding applications. Compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).
|
Model Name/Number |
LC1D09 M7 |
|
Number Of Poles |
3 Pole |
|
Brand |
SCHNEIDER |
|
Coil operating Voltage |
220V AC |
|
Mounting Type |
DIN Rail |
|
Rated Current (AC-3) upto 415V AC |
9 Amps |
|
AC-3 DUTY |
5.5HP |
|
Motor KW upto 415V AC, 3PH |
4KW |
|
Rated operational Current (AC-1) |
25A |
|
AUX. CONTACT |
1NO+1NC |
ALSO AVAILABLE in OTHER COIL VOLTAGES 24V AC,110V AC, 415V AC, 24V DC
